Integrated spindle drives with 2950.2 ft lb Nm at the main spindle for maximum cutting performance
- Optional counter spindle for 6-sided complete machining with up to 2,200 Nm
- Material removal rate ISM 102 to 0.1 ft3 / min (CK45)
- Integrated C-axis (0.001 °)
Complex turning and milling operations with an ultra-compact Turn&Mill spindle with 162.3 ft lb torque
- Turning and milling spindle compactMASTER with 12,000 rpm, 48.3 hp and 162.3 ft lb - available as high-speed version with 20,000 rpm
- 16.5 in Y-stroke for more flexibility
- Automatic tool change. 36-fold disc magazine in standard, max. 180 stations in the optional chain magazine.
Optional second tool carrier for highly productive turn & mill machining
- VDI 40 turret rated at 4,000 rpm, 20.7 ft lb and 13.4 hp or VDI 40 Direct Drive turret rated at 10,000 rpm, 25.1 ft lb and 19 hp
- "< 30 sec. tool set-up time and < 0.2 μin repeatability with
- TRIFIX® precision quick-change interface as standard"
- Easy to use turret steady rests and turret centers with the technology cycle (optional)
Accuracy
Maximum precision and temperature stability
- Direct measuring systems in all axes by Magnescale
- Cooling of the X / Y / Z-axis motors and the turret drives
- Maintenance-free linear drive in the Z-axis * with 5 years warranty
