MV1200-S ADVANCE TYPE M800
Brand：Mitsubishi EDM
Photo credit: Mitsubishi EDM
Rating
(0)
0
Write a review
Introduction
MV-S NewGen
Economical production by combination of high cutting speed and the trend-precision and low consumption. The MV-S series with the non-contact and therefore wear-free direct drive Tubular opens a new chapter for Eroding. Less wire consumption and less power consumption ensure economic benefits that pay off year after year. Reliable, man-free operation is ensured by the patented wire threading around the clock.
Specifications
Machine Type
線切割
Max Part Size (L) (inch)
31.9
Max Part Size (D)(inch)
27.6
Max Part Size (H)(inch)
8.5
Max Part Weight (lbs)
1102
Table Length (inch)
25.2
Table Depth (inch)
17.7
Work Tank Dielectric cap. (gal)
145
X Travel (inch)
15.7
Y Travel (inch)
11.8
Z Travel (inch)
8.7
X Rapid (ipm)
51
Y Rapid (ipm)
51
Z Rapid (ipm)
51
U Travel (inch)
2.4
V Travel (inch)
2.4
Max. Taper Angle
45
Max. Wire Diameter
0.012
Min. Hole Diameter (inch)
0.02
Max. Wire spool weight (lbs)
22
×
